LPG Powered Forklift
LPG forklifts have lower emissions than diesel ones;
They produce no black smoke and comply with environmental regulations;
Fuel storage is safe with a low risk of leakage;
They are suitable for both indoor and outdoor operations without pollution issues.
Product Overview This LPG forklift is specifically designed for short-to-medium distance material handling in warehousing, logistics, and manufacturing industries. Powered by liquefied petroleum gas, it balances efficient operation with environmental protection, making it suitable for flexible use in indoor, semi-outdoor, and other multi-scene environments.
The price of liquefied petroleum gas is stable and not affected by fluctuations in oil prices; the engine has a long service life, reducing overhaul costs; it is suitable for high-intensity operations with lower operating costs; there is no waiting time for charging, which improves work efficiency.
Product Parameter
TECHNICAL SPECIFICATIONS | ||||
Performance | Model | CPC30∕CPCD30 | ||
Rated Capacity | kg | 3000 | ||
Load Center | mm | 500 | ||
Power Type | Diesel | |||
Max. Lifting Speed (No-Load / Full-Load) | mm/s | 450∕440 | ||
Max. Driving Speed (Full-Load / No-Load) | km/h | 18∕20 | ||
Max. Towing Capacity | kN | 15.5∕10.5 | ||
Gradeability (Full-Load / No-Load) | % | 15∕20 | ||
Lifting Height | (H1) | mm | 3000 | |
Free Lift Height | mm | 80 | ||
Mast Tilting Angle (Forward-Backward) | （°） | 6∕12 | ||
Min. Turning Radius | mm | 2530 | ||
Min.Right Angle Aisle Width | mm | 2050 | ||
Min. Ground Clearance | mm | 135 | ||
Dimensions | Overall Length (Including Fork) | (A) | mm | 4170 |
Overall Width | (B) | mm | 1230 | |
Overall Height (Mast Lowered) | (H) | mm | 2110 | |
Overall Height (Mast Extended) | (H2) | mm | 4270 | |
Overall Height to Overhead | (H3) | mm | 2105 | |
Front Overhang | (A1) | mm | 465 | |
Wheelbase | (A2) | mm | 1760 | |
Front Tread | (B1) | mm | 1000 | |
Rear Tread | (B2) | mm | 970 | |
Tire | Front Wheel | mm | 28*9-15 | |
Rear Wheel | mm | 6.50-10 | ||
Fork | Fork Width | (B3) | mm | 122 |
Fork Thickness | (H4) | mm | 45 | |
Backrest Height | mm | 1225 | ||
Fork Length | (A3) | mm | 1220 | |
Type of Power Shift | Mechanical∕Hydraulic | |||
Optional LPG Engine | Engine Model | Nissan K25 | ||
Rated Power | kW | 37.4 | ||
Rotate Speed at Rate Power | rpm | 2300 | ||
Max. Torque | Nm | 176.5 | ||
Rotation Speed at Max. Torque | rpm | 1600 | ||
Optional LPG Engine | Engine Model | Guangqing | ||
Rated Power | kW | 39 | ||
Rotate Speed at Rate Power | rpm | 2800 | ||
Max. Torque | Nm | 156 | ||
Rotation Speed at Max. Torque | rpm | 1800 | ||
Optional
1. Engine：
•Standard: Guangqing
•Optional: Nissan (Japan)
2. Mast：
•Standard: 2-stages 3000mm
•Optional: 2-stages and 3-stages full free 4500mm-7500mm mast
3. Fork：
•Standard 1220mm fork
•Optional 1370mm, 1520mm, 1670mm and 1820mm forks;
4. Pneumatic tire and solid tire both available
5. All kinds of forklift attachments available
Why TIGLIFT LPG Forklift？
Product Advantages Low-Noise Operation: Equipped with a low-noise power system, the operating noise is lower than industry standards, reducing interference to operators and the surrounding environment.
Convenient Gas Supply: The gas tank and body are integrated in layout, enabling easy refueling without occupying cargo space. Ergonomic Design: The operating handle conforms to ergonomic principles, with precise and lightweight steering, reducing driver fatigue. Comprehensive Safety Protection: Features multiple safety safeguards (such as automatic gas path cutoff and overload warning) to ensure operational safety.
Strength of the Manufacturing Plant
Covering an area of over 100,000 square meters, the plant has a complete production line with four major processes: stamping, welding, painting, and final assembly. The welding process introduces automated robots to ensure the connection strength and consistency of key components. Each forklift undergoes more than 30 rigorous tests before leaving the factory (including load testing, braking testing, and air tightness testing).
Shipping Services Supports direct transportation to multiple ports worldwide. Regular orders are shipped in full container loads (20ft/40ft containers compatible with different models). The factory has its own container yard to ensure efficient loading and unloading. Provides air freight for bulk cargo consolidation services for urgent orders to shorten the delivery cycle. Each forklift is packaged with shockproof reinforcement before shipment (with buffer wooden pallets added at the bottom and critical parts wrapped in anti-collision film), accompanied by a detailed packing list and operation guide. Delivery Photos
After-Sales Service Commits to responding within 48 hours upon receiving fault feedback. Has a sound spare parts supply system: conventional wearing parts (such as gas valves and filters) are stocked in global warehouses, and can be delivered by air priority in emergency situations. Offers remote technical guidance to assist overseas customers in solving basic operation and maintenance issues; dispatches engineers for on-site service when necessary.
