Wheel Loader

Skid steer loaders excel with their core advantage of "one machine, multiple uses":

Versatile Attachments: By quickly switching attachments (such as buckets, breakers, sweepers, etc.), they can flexibly transition between various engineering scenarios—excavation, loading, crushing, cleaning, and more—greatly improving equipment utilization.

Compact Design: Their compact body allows easy movement in narrow workspaces (e.g., indoor renovation sites, urban alley reconstruction) with an extremely small turning radius, adapting to complex construction environments.

Easy Operation: The intuitive operation system enables drivers to master skills after short-term training, reducing labor costs.

Stable Power: The power system delivers consistent output, maintaining high efficiency whether in heavy-duty excavation or light cleaning tasks.

Convenient Maintenance: Key components are centrally arranged, minimizing time spent on daily inspections and maintenance.

Contact Now E-Mail Telephone WhatsApp

Product Details

The comfort features of this skid steer loader:

A fully sealed cab isolates noise;

a suspended seat reduces vibration;

large-vision glass ensures no blind spots;

and an air conditioning system maintains a comfortable temperature.

Special configurations of the skid steer loader:

LED work lights ensure night construction;

a camera system eliminates blind areas;

heated seats enhance winter comfort;

wipers keep the view clear;

USB interfaces facilitate device charging.

Product Parameter

SPECIFICATIONS AW45
	Parameters	Unit (Metric)	Unit(inch)
Dimensions	Operating Height	3660mm	144 in
	Max Hinge Pin Height	3079mm	121 in
	Height To Top	2230mm	87.8 in
	Overall Length with Std.Bucket	3276mm	129 in
	Overall Length Without Attachment	2325mm	91.5 in
	Wheelbase	991mm	39 in
	Overall Width	1726mm	68 in
	Mini Ground Clearance	185mm	7.3 in
	Angle Of Departure	20°	20°
	Bucket Capacity	0.4CBM	106 gal
	Rated Loading Capacity	700kgs	1543 lb
	Machine Weight	2600kgs	5732 lb
Hydraulic system	Working System Pressure	22Mpa	3191psi
	Working System Flow Rate	80L/min	21.13 gpm
	Driving System Pressure	25Mpa	3626 psi
	Driving System Flow Rate	105L/min	27.74 gpm
Engine	Engine Model	XINCHAI490(State II)
	No. Of Cylinders	4 Cylinder	4 Cylinder
	Net Power	42kw	56.32 hp
	Note: Optional Engine Korean LS(EPA)-42.5Kw/1.9L

Strength of the Manufacturing Plant

With 20 years of focus on R&D and manufacturing of construction machinery, the plant features:

Intelligent production lines and automated welding equipment to ensure the strength of frames and structural parts meets standards.

A quality inspection center certified by the ISO 9001 quality management system. Each skid steer loader undergoes three rigorous tests before leaving the factory: no-load testing, load operation testing (simulating full-shovel working conditions), and extreme environment simulation (high temperature/low temperature/humidity).

A R&D team composed of multiple mechanical and hydraulic engineers, who regularly collect global customer needs to optimize product design.

International Shipping Services

Supports direct shipping to multiple ports worldwide, offering flexible full container load (FCL) and less than container load (LCL) options.

Before shipment, the entire machine undergoes rust-proof treatment; attachment interfaces and hydraulic pipelines are equipped with protective sleeves to prevent collision damage during transportation.

Cooperating with international logistics providers covering sea freight (20-40ft containers), land transport (China-Europe Railway Express), and air freight (for urgent orders), the entire process from factory to port is tracked, ensuring delivery to major global ports within 45 days.

International After-Sales Service

Warranty: 2 years or 2,000 hours (whichever comes first) warranty for core components (hydraulic pumps, transmission systems, attachment connection mechanisms).

Market Coverage & Response: Covering major markets in Europe, America, Southeast Asia, the Middle East, etc., with a 48-hour response commitment.

Technical Support: A remote technical support team provides video guidance to resolve common faults.

Spare Parts Delivery: Common parts such as filters and seals can be delivered to the customer’s designated location within 10 working days.
