3T Electric Forklift
1. It adopts high-safety lithium iron phosphate batteries with a cycle life of over 4,000 times and supports fast charging.
2. Equipped with an intelligent power management system, it can monitor the battery status in real time, effectively enhancing the battery life.
3. Equipped with a high-power permanent magnet synchronous motor, it features strong power, climbing ability up to 15%, smooth operation and low noise.
4. Ergonomic design, equipped with a suspended seat, provides comfortable operation and effectively reduces driver fatigue during work.
5. Metal body structure with key components having a high protection level, can adapt to various complex working conditions and significantly enhance durability.
In modern warehousing, logistics and manufacturing, efficient, environmentally friendly and low-cost material handling solutions have become the key for enterprises to enhance their core competitiveness. Our 3t electric forklift is a high-performance product meticulously crafted to meet this market demand. It is not only an ideal alternative to traditional internal combustion forklifts but also the future choice leading green and intelligent material handling. The 3t electric forklift has advantages such as zero emissions and low noise during operation, and is perfectly suitable for indoor places with strict environmental requirements such as food, medicine, and cold chain. The battery contains no heavy metals or corrosive liquids, making it safer and more environmentally friendly.
Core performance advantage: The perfect integration of power, efficiency and intelligence
1. Powerful and stable power system
This vehicle is equipped with an industry-leading high-power permanent magnet synchronous motor. Compared with traditional asynchronous motors, it has a higher energy conversion efficiency (over 95%) and a wider high-efficiency range. This means that it not only has a rapid response in terms of starting, accelerating and climbing power, capable of easily handling the challenge of a 15% slope, but also ensures a stable and powerful output even under heavy load conditions. With the precise electronic control system, the vehicle runs smoothly and smoothly, greatly enhancing the stability and safety of goods handling.
2. Ultra-long battery life and fast charging
High energy density and long cycle life lithium iron phosphate battery packs are adopted as the power source. This battery technology features high safety and a cycle life of over 4,000 times, significantly reducing the cost of battery replacement throughout its entire life cycle. Innovative intelligent charging technology supports fast charging, meeting the intermittent power replenishment needs of multi-shift production operations.
3. Intelligent energy management and monitoring
The forklift is integrated with an advanced intelligent power management system, which can precisely monitor the battery's voltage, current, temperature and remaining power in real time, and provide feedback to the operator through an intuitive LCD screen. The system can perform intelligent charging and discharging control and fault early warning. It not only effectively prevents overcharging and overdischarging of the battery and extends its life, but also helps fleet managers scientifically plan operation tasks through precise power calculation, achieving the optimization of energy utilization.
Model | CPD30 | ||
Rated Capacity | kg | 3000 | |
Load Center | mm | 500 | |
Power Type | Lithium Battery | ||
Driving Type | Ride-on Type | ||
Wheelbase | (A2) | mm | 1760 |
Front Tread | (B1) | mm | 1000 |
Rear Tread | (B2) | mm | 970 |
Front Overhang | (A1) | mm | 465 |
Mast Tilting Angle (Forward-Backward) | ° | 6∕12 | |
Max. Lifting Height | (H1) | mm | 3000 |
Free Lift Height | mm | 80 | |
Overall Height (Mast Lowered) | (H) | mm | 2110 |
Overall Height (Mast Extended) | (H2) | mm | 4270 |
Overall Height to Overhead | (H3) | mm | 2105 |
Overall Length (Including Fork) | (A) | mm | 4060 |
Overall Width | (B) | mm | 1230 |
Min. Ground Clearance | mm | 135 | |
Min. Turning Radius | mm | 2530 | |
Fork Dimensions (L×W×T) | mm | 122*45*1220 | |
Max. Driving Speed (No-Load) | km/h | 14 | |
Max. Driving Speed (Full-Load) | km/h | 13 | |
Max. Lifting Speed (Full-Load / No-Load) | mm/s | 270∕300 | |
Gradeability (Full-Load / No-Load) | % | 15∕20 | |
Tire Type (Front/Rear) | 充气胎 Pneumatic Tire | ||
Tire Size (Front/Rear) | 28*9-15-14PR/6.50-10-10PR | ||
Drive Motor Power (S2-60min) | kW | 14 | |
Lifting Motor Power (S3-15%) | kW | 16 | |
Drive Motor Type | AC | ||
Lifting Motor Type | AC | ||
Hydraulic System Pressure | MPa | 18 | |
Battery (Voltage/Capacity) | V/Ah | 76.8V/205Ah | |
Curb Weight | kg | 4100 |
Wide application scenarios: Compatible with various complex working conditions
Indoor warehousing and logistics center
This is the natural home ground for lithium battery forklifts. Its absolute advantages of zero emissions and low noise (operating noise below 65 decibels) make it perfectly suitable for indoor environments with strict air quality requirements, such as the food, pharmaceutical, electronic, cold chain and other industries. A clean working environment helps ensure product quality and creates a healthier and more comfortable working atmosphere for employees at the same time.
2. High-intensity multi-shift manufacturing industry
In manufacturing plants of automobiles, home appliances, building materials, etc., material handling operations are frequent and intense. This vehicle is equipped with fast charging and strong power, which can seamlessly connect with the production rhythm and ensure the timely supply of materials. Its high reliability and low failure rate ensure the continuous and stable operation of the production line. Compared with internal combustion forklifts, the significantly reduced energy consumption and maintenance costs directly bring considerable economic benefits to enterprises.
3. Special scenarios with strict environmental requirements
In public places such as airports, railway stations, libraries and museums, as well as industries sensitive to dust like tobacco and textiles, the environmental protection features of electric forklifts are irreplaceable. In addition, the vehicle's robust body design and excellent off-road performance also enable it to handle some slightly harsh outdoor storage yards or semi-open-air workshops, demonstrating strong environmental adaptability.
In conclusion, this 3t electric forklift has redefined the standards for 3-ton material handling equipment through its three core features: powerful performance, ultra-long range, and intelligent management. It can not only comprehensively cover various complex application scenarios from indoor warehousing to outdoor manufacturing, but also bring about a significant reduction in operating costs and an increase in long-term return on investment for users through its outstanding environmental friendliness and economy. Choosing it means choosing a more efficient and sustainable way of working in the future.
