Forklift Truck
Direct injection diesel technology ensures higher fuel utilization;
A single tank of fuel supports 12 hours of operation, delivering remarkable efficiency;
No reliance on electricity, enabling worry-free field operations;
Reinforced chassis for stronger bump resistance.
Another advantage of diesel forklifts is their long maintenance intervals: regular maintenance (oil and filter replacement) is performed every 500 hours, which is more time-efficient than electric forklifts (which require battery checks every 200 hours); the engine oil replacement interval reaches 2,000 hours, reducing the frequency of downtime for maintenance; key parts of the entire vehicle adopt maintenance-free bearings, lowering the cost of daily inspections.
Product Parameter
TECHNICAL SPECIFICATIONS | |||||
Performance | Model | CPC40 | CPCD40 | ||
Rated Capacity | kg | 4000 | 4000 | ||
Load Center | mm | 500 | 500 | ||
Power Type | Diesel | Diesel | |||
Max. Lifting Speed (No-Load / Full-Load) | mm/s | 470∕420 | 470∕420 | ||
Max. Driving Speed (Full-Load / No-Load) | km/h | 18∕20 | 18∕20 | ||
Max. Towing Capacity | kN | 16.5∕11.5 | 16.5∕11.5 | ||
Gradeability (Full-Load / No-Load) | % | 15∕20 | 15∕20 | ||
Lifting Height | (H1) | mm | 3000 | 3000 | |
Free Lift Height | mm | 80 | 80 | ||
Mast Tilting Angle (Forward-Backward) | （°） | 6∕12 | 6∕12 | ||
Min. Turning Radius | mm | 2540 | 2540 | ||
Min.Right Angle Aisle Width | mm | 2050 | 2050 | ||
Min. Ground Clearance | mm | 135 | 135 | ||
Dimensions | Overall Length (Including Fork) | (A) | mm | 4170 | 4170 |
Overall Width | (B) | mm | 1230 | 1230 | |
Overall Height (Mast Lowered) | (H) | mm | 2130 | 2130 | |
Overall Height (Mast Extended) | (H2) | mm | 4270 | 4270 | |
Overall Height to Overhead | (H3) | mm | 2130 | 2130 | |
Front Overhang | (A1) | mm | 465 | 465 | |
Wheelbase | (A2) | mm | 1735 | 1735 | |
Front Tread | (B1) | mm | 1000 | 1000 | |
Rear Tread | (B2) | mm | 970 | 970 | |
Tire | Front Wheel | mm | 2.50-15 | 2.50-15 | |
Rear Wheel | mm | 6.50-10 | 6.50-10 | ||
Fork | Fork Width | (B3) | mm | 122 | 122 |
Fork Thickness | (H4) | mm | 50 | 50 | |
Backrest Height | mm | 1225 | 1225 | ||
Fork Length | (A3) | mm | 1220 | 1220 | |
Engine | Engine Model | C490BPG | C490BPG | ||
Rated Power | kW | 40 | 40 | ||
Rotate Speed at Rate Power | rpm | 2650 | 2650 | ||
Max. Torque | Nm | 162 | 162 | ||
Rotation Speed at Max. Torque | rpm | 1800～1900 | 1800～1900 | ||
Type of Power Shift | Mechanical | Hydraulic | |||
Self-Weight | kg | 4600 | 4600 | ||
Optional
1. Engine：
•Standard: Xinchai, Quanchai
•Optional: Isuzu (Japan), Mitsubishi (Japan), Nissan (Japan), YANMAR(Japan), Kohler (USA), Commins (USA)
2. Mast：
•Standard: 2-stages 3000mm
•Optional: 2-stages and 3-stages full free 4500mm-7500mm mast
3. Fork：
•Standard 1220mm fork
•Optional 1370mm, 1520mm, 1670mm and 1820mm forks;
4. Pneumatic tire and solid tire both available
5. All kinds of forklift attachments available
Why TIGLIFT Diesel Forklift？
Diesel Forklifts: The First Choice for Construction Sites
Construction sites prioritize diesel forklifts for their ability to adapt to rough terrain. Diesel engines are resistant to dust, making them suitable for gravel-rich environments. Free from reliance on electricity, they operate seamlessly even in remote outdoor areas. Additionally, their reinforced suspension systems offer superior bump resistance.
"All-Round Adaptability" as the Key Reason for Construction Site Preference
Construction sites choose diesel forklifts primarily for their "all-round adaptability":
They can drive stably on rough surfaces like gravel and mud, with wear-resistant tires featuring adjustable air pressure.
Unrestricted by electricity, they function reliably in off-road areas.
Dust-proof designs ensure trouble-free operation in dusty environments such as cement plants and demolition sites.
Reinforced suspension systems reduce thrashing, protecting transported goods like building materials and pipes.
Delivery Photos
Proactive Customer Experience Assurance
Beyond passive issue resolution, we take initiative to safeguard customer experience through the following measures:
Quarterly Usage Tracking: Send quarterly emails to customers with updates on product usage status, including maintenance recommendations and self-check guides for common faults, helping them proactively manage equipment performance.
Annual Free Upgrades: Provide at least one free remote system upgrade service per year (applicable to smart devices or software-linked products), ensuring customers always have access to optimized functionality.
Warranty Expiry Reminders: Proactively notify customers 30 days before their product warranty expires, outlining renewal or maintenance options. This helps them plan equipment lifecycle management in advance, avoiding unexpected disruptions.
These proactive efforts aim to support customers in maximizing equipment efficiency and minimizing operational risks throughout the product’s lifespan.
